Frame Available:
ASTM A234 grade WPB, in compliance with ANSI B16.28 or SG Iron as per IS 1865-1991
Steel Pc:
According to SCH 40 up to 8”, according to SCH 20 from 10” to 12”.
Flange:
ASTM A105, incompliance with ANSI B16.5/Class 150lbs; JIS 10K or DIN is also available on request
Standard:
Four fixed flanges; four loose flange or two fixed flanges or two loose flanges or one fixed flange and three loose flanges are on request
Lining Available:
PTFE/FEP/FEA
